INPR08-32 Pressure Reducing / Relieving Valve

A screw-in, cartridge-style, direct-acting, spool-type, hydraulic pressure reducing/relieving valve with internal pilot and internal spring chamber drain, designed to act as a pressure-regulating device for secondary circuits. It is intended for use in stable input flow circuits.

In its steady state, the INPR08-32 allows flow to pass bidirectionally from port 2 to port 1, with the spring chamber constantly drained at port 3. On attainment of a pre-determined pressure at port 1, the cartridge shifts to block flow at port 2, thereby regulating pressure at port 1. In this mode, the valve also will relieve port 1 to port 3 at a variable value over the set reducing pressure. Note: Direct-acting PR series valves may not be suitable for some static load applications. Consult factory.
